Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard

Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Save: 300৳
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard

Key Features

  • Supports 11th and 10th Gen Intel Core Processors
  • Dual-Channel DDR4, 2 DIMMs
  • Ultra-Fast M.2 with PCIe Gen3 X4
  • 4 Display Interfaces Support
  • Offer Price: 8,700৳
  • Price: 9,000৳
  • Stock: In Stock
  • Brand: Gigabyte
  • Model: H510M S2H
  • SKU: 10171
Based on 0 reviews. - Write a review
8,700৳
9,000৳
Ex Tax: 8,700৳
Add to Cart
Buy Now
WishList Compare
Main Features
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset Intel H510 Express Chipset
Form Factor Micro ATX Form Factor; 24.4cm x 21.0cm
Supported CPU 11th Generation Intel Core i9 processors /
Intel Core i7 processors / Intel Core i5 processors
10th Generation Intel Core i9 processors /
Intel Core i7 processors / Intel Core i5 processors /
Intel Core i3 processors/ Intel Pentium processors /
Intel Celeron processors
* Limited to processors with 4 MB Intel Smart Cache, Intel Celeron G5xx5 family.
Expansion Slots
M.2 Socket 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
PCI 1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 4.0 standard.)
* Supported by 11th Generation processors only.
2 x PCI Express x1 slots
(The PCI Express x1 slots conform to PCI Express 3.0 standard.)
Graphics Specifications
Graphics Integrated Graphics Processor-Intel HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
* When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI ports, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
* When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
Support for up to 2 displays at the same time
Max Shared Memory 512MB
Memory Specifications
Maximum Size 64 GB (32 GB single DIMM capacity)
Slot 2 x DDR4 DIMM
Supported Memory 11th Generation Intel Core i9/i7/i5 processors:
Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
10th Generation Intel Core i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/2400/2133 MHz memory modules
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Type Dual-channel architecture
Connectivity
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Audio Jack 3 x audio jacks
D-Sub 1 x D-Sub port
Display Port 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
DVI 1 x DVI-D port
HDMI 1 x HDMI ports, supporting a maximum resolution of 4096x2160@30 Hz
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x speaker header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x Clear CMOS jumper
LAN Ports Realtek GbE LAN chip (1 Gbit/100 Mbit)
Supported Storage 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
* The PCIEX1_1 slot shares bandwidth with the M.2 connector.
When the PCIEX1_1 slot is populated,
the M.2 connector supports up to PCIe 3.0 x2 SSD only.
4 x SATA 6Gb/s connectors
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
USB Chipset:
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports
available through the internal USB header)
Chipset+USB 2.0 Hub:
8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available
through the internal USB header)
Warranty Information
Manufacturing Warranty 03 Years
Others
Bundled Software Norton Internet Security (OEM version)
Realtek 8118 Gaming LAN Bandwidth Control Utility
Special Features Support for APP Center
@BIOS
Ambient LED
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
Smart Backup
System Information Viewer
Support for Q-Flash
Support for Xpress Install

Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard

Gigabyte H510M S2H Intel 10th and 11th Gen Micro ATX Motherboard - a great choice for your next system build! Equipped with main features such as BIOS with 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0, Intel H510 Express Chipset, Micro ATX Form Factor and supported CPU 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors 10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors. Expansion slots for 1 x M.2 connector, 1 x PCI Express x16 slot, 2 x PCI Express x1 slots and graphics specifications includes 1 x D-Sub port, 1 x DVI-D port, 1 x HDMI port, 1 x DisplayPort, Integrated Graphics Processor-Intel HD Graphics support, Max Shared Memory-512MB and so much more! Experience easy connectivity through audio Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel, Audio Jack-3 x audio jacks, D-Sub-1 x D-Sub port, DisplayPort-1 x DisplayPort, DVI-1 x DVI-D port, HDMI-1 x HDMI ports, Internal I/O Ports-1 x 24-pin ATX main power connector, LAN Ports-Realtek GbE LAN chip (1 Gbit/100 Mbit), Supported Storage-1 x M.2 connector, 4 x SATA 6Gb/s connectors, TPM (Trusted Platform Module )-1 x Trusted Platform Module header, USB-Chipset-4 x USB 3.2 Gen 1 ports and much more in a 03 years Manufacturing Warranty with bundled software such as Norton Internet Security (OEM version), Realtek 8118 Gaming LAN Bandwidth Control Utility, Support for APP Center, @BIOS, Ambient LED, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, Smart Backup, System Information Viewer, Support for Q-Flash, Support for Xpress Install and more.

Features:

The Gigabyte H510M S2H is a micro ATX motherboard designed for Intel 10th and 11th generation processors. Here are some of its key features:

  • Supports 11th and 10th Gen Intel®  Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
  • Ultra-Fast M.2 with PCIe Gen3 X4 & SATA Interface
  • GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
  • 4 Display Interfaces Support
  • High Quality Audio Capacitors and Audio Noise
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • GIGABYTE APP Center, Simple and Easy Use
  • Anti-Sulfur Resistors Design

 Overall, the Gigabyte H510M S2H is a solid choice for a micro ATX build, offering good performance and a range of features at an affordable price point.
