Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard

Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Save: 1000৳
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard

Key Features

  • Supports 11th and 10th Gen Intel Core Processors
  • Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2
  • Dual-Channel DDR4, 4 DIMMs
  • Dual-Band 802.11ac Wireless & BT 4.2
  • Offer Price: 12,500৳
  • Price: 13,500৳
  • Stock: In Stock
  • Brand: Gigabyte
  • Model: B560M DS3H AC
  • SKU: 10339
Based on 3 reviews. - Write a review
12,500৳
13,500৳
Ex Tax: 12,500৳
Add to Cart
Buy Now
WishList Compare
Main Features
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset Intel B560 Express Chipset
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Supported CPU 11th Generation Intel Core i9 processors / Intel Core i7 processors /
Intel Core i5 processors
10th Generation Intel Core i9 processors / Intel Core i7 processors /
Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium
processors / Intel Celeron processors
Expansion Slots
M.2 Socket 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0
x4/x2 SSD support) (M2P_CPU) (Note)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe
3.0 x4/ x2 SSD support) (M2A_SB)
PCI 1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)
2 x PCI Express x1 slots
(The PCIEX1 slot conforms to PCI Express 3.0 standard.)
Graphics Specifications
Graphics Integrated Graphics Processor-Intel HD Graphics support:
1 x DisplayPort, supporting a maximum resolution of
4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
* When the D-Sub port and DisplayPort are connected at the same
time, images will output from the DisplayPort only.
1 x HDMI port, supporting a maximum resolution of
4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
Max Shared Memory 512MB
Memory Specifications
Maximum Size 128 GB (32 GB single DIMM capacity)
Slot 4 x DDR4 DIMM
Supported Memory 11th Generation Intel Core i9/i7/i5 processors:
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4
5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)
/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) /
4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.)
/ 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.)
/ 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz
10th Generation Intel Core i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/2400/2133 MHz memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single
DIMM capacity) of system memory
Dual-channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
(operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
memory modules
Support for Extreme Memory Profile (XMP) memory modules
Type Dual-channel memory architecture
Connectivity
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Audio Jack 3 x audio jacks
D-Sub 1 x D-Sub port
Display Port 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
DVI 1 x DVI-D port
HDMI 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Clear CMOS jumper
1 x Q-Flash Plus button
LAN Ports Realtek GbE LAN chip (1000/100 Mbit)
Supported Storage 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe
4.0 x4/x2 SSD support) (M2P_CPU) (Note)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe
3.0 x4/ x2 SSD support) (M2A_SB)
6 x SATA 6Gb/s connectors
Intel Optane Memory Ready
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/
GC-TPM2.0 SPI 2.0 module only)
USB Chipset:
1 x USB Type-C port on the back panel, with USB 3.2 Gen 1
support
5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports
available through the internal USB header)
4 x USB 2.0/1.1 ports available through the internal USB headers
Chipset+USB 2.0 Hub:
2 x USB 2.0/1.1 ports on the back panel
Warranty Information
Manufacturing Warranty 3 Years
Others
Bundled Software Norton Internet Security (OEM version)
Realtek 8118 Gaming LAN Bandwidth Control Utility
Special Features Support for APP Center
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install

Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard

The Gigabyte B560M DS3H AC Micro ATX Motherboard provides a cutting-edge performance and all the latest features coveted by even the most demanding of users. It supports both 11th and 10th Gen Intel® Core™ Series Processors, Dual Channel Non-ECC Unbuffered DDR4 with 4 DIMMs for a robust computing experience. It is also equipped with a Direct 6+2 Phases Digital VRM solution with lower RDS(on) MOSFETs for reliable power delivery. On top of that, the board features Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 slots to enable blazing fast data transfer speeds. For connectivity, this premium motherboard comes with exclusive GIGABYTE 8118 Gaming LAN with Bandwidth Management, Onboard Dual Band 802.11ac Wireless & BT 4.2 with WIFI Antenna and USB 3.2 Gen1 Type-C® for fast and versatile connections. Last but not least, it also features High Quality Audio Capacitors and Audio Noise Guard, RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips, Smart Fan 6 and Q-Flash plus to make updating the BIOS simpler.

Features:

Some of the features of this Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard include-

  • Supports 11th and 10th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Direct 6+2 Phases Digital VRM Solution with Low RDS(on) MOSFETs
  • Dual Ultra-Fast NVMe PCIe 4.0/3.0* x4 M.2
  • GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
  • Onboard Dual Band 802.11ac Wireless & BT 4.2 with WIFI Antenna
  • USB 3.2 Gen1 Type-C® for Fast and Versatile Connections
  • High Quality Audio Capacitors and Audio Noise Guard
  • RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

Overall, the Gigabyte B560M DS3H AC is a good choice for users who want a compact and affordable motherboard with the latest features and support for both 10th and 11th Gen Intel processors.
